Victron 12V 60W Polycrystalline Solar Panel

Durable 60W Poly Solar Panel for Off-Grid and Mobile Power

Built for reliability in mobile and off-grid environments, the Victron 12V 60W Poly Solar Panel is a versatile energy solution designed to power 12V battery systems with maximum efficiency. Featuring high-grade polycrystalline cells, a rugged aluminium frame, and long-life construction, it’s an ideal fit for marine use, RVs, caravans, cabins, and tiny houses. Dependable, portable, and ready for solar expansion.

Key Features

• High-efficiency polycrystalline solar panel

• 60W power output designed for 12V battery systems

• Durable silver anodized aluminium frame

• Triple-layer EVA backsheet ensures protection and performance

• Low voltage-temperature coefficient for enhanced high-temp output

• Great low-light sensitivity and wide-spectrum performance

• Built-in bypass diodes to reduce power loss from shading

• Sealed waterproof junction box for safe, long-lasting operation

• Compatible with PWM and MPPT charge controllers

• Backed by 5-year product and 25-year power performance warranties

Specs

• Module: SPP040601200

• Nominal Power (±3%): 60W

• Cell Type: Polycrystalline

• Number of Cells: 36 (in series)

• Maximum System Voltage: 1000V

• Temperature Coefficient (PMPP): -0.45% / °C

• Temperature Coefficient (Voc): -0.35% / °C

• Temperature Coefficient (Isc): +0.04% / °C

• Temperature Range: -40°C to +85°C

• Surface Load Capacity: 200 kg/m²

• Allowable Hail Load: 23 m/s, 7.53 g

• Junction Box Type: PV-LH0801

• Cable/Connector: No cable included

• Output Tolerance: ±3%

• Frame: Aluminium

• Product Warranty: 5 Years

• Performance Warranty: 10 years @ 90%, 25 years @ 80% output

• Dimensions: 545 x 668 x 25 mm

• Net Weight: 4.0 kg

Electrical Data Under STC:

• Nominal Power (PMPP): 60W

• Max Power Voltage (VMPP): 19.3V

• Max Power Current (IMPP): 3.12A

• Open Circuit Voltage (Voc): 23.10V

• Short Circuit Current (Isc): 3.37A

What’s Included

• 1 × Victron 12V 60W Polycrystalline Solar Panel

• Integrated waterproof junction box

• Pre-mounted aluminium frame

• PV-ST01-ready quick-connect terminals
